AK45
Portable Nitrite Meter
Handheld photometer for nitrite with a 0 to 150 ppm range and one-button operation for immediate, accurate field results.
0 to 150 ppmNitrite Range
± 3 ppm +5% readingNitrite Accuracy
Portable Nitrite Meter
Handheld photometer for nitrite with a 0 to 150 ppm range and one-button operation for immediate, accurate field results.
The Nitrite Tester is accurate, affordable, lightweight, yet robust for field use. The tester line of photometers is handy and can be easily transported anywhere you need them to go. The one-button operation makes it simple to use getting immediate and accurate results.
No more struggling to determine colours with Test Kits, our handheld photometers take the hassle out of matching to a colour chart, providing a direct and precise result.
Nitrite is added to water in cooling towers at high concentrations to act as a corrosion inhibitor.
Food Industry uses Nitrite compounds as preservatives.
It is present in low concentrations in surface waters and rarely in groundwaters.
In wastewaters, nitrite concentrations are often higher.
Nitrite is produced during the bacterial oxidation of ammonia and in the reduction of nitrate.
Applications
Rapid checks for dairy, beverages, sauces, and process-line compliance.
Field testing for municipal and industrial water treatment monitoring.
Keep display and breeding tanks stable — pH, ammonia, nitrite and dissolved oxygen.
| Measurement Specifications | |||
| Parameter | Range | Resolution | Accuracy |
|---|---|---|---|
| Nitrite | 0 to 150 ppm | 1 ppm | ± 3 ppm +5% reading |
| General Specifications | |
| Operating temperature | 0 to 50 °C |
| Sample temperature | 15 to 35 °C |
| Measuring cell | Glass cuvette Ø 18.8 mm (12 mL) |
| Sample volume | 10 mL |
| Light source | Light Emitting Diodo (LED) |
| Wavelength | 575 nm |
| Display | OLED |
| Languages | English, Spanish, Italian, Portuguese |
| Auto power-off | After 2 minutes |
| Operating humidity | 10 to 90 % RH (non-condensing) |
| Power supply | 9 VDC (1 × 9 V battery) |
| Dimensions | 73 x 77 x 40 mm |
| Weight | 120 g (with battery) |
| Measurement method | Colorimetric method based on the reaction of ferrous sulfate in an acidic medium. |
Replacement parts, calibration solutions, and maintenance supplies for the AK45.
